ProSense Digital Panel Meters from AutomationDirect

January 21, 2020

AutomationDirect ProSense digital panel meters in 1/32 and 1/8 DIN sizes are AC or DC powered and feature IP65-rated meter faces, simple menu-driven pushbutton configuration, and accept a wide variety of input signals. Available outputs include alarm relays, milliamp current, and sensor excitation voltage options.

New process-display options now include (depending on series) AC or DC voltage (20/100/200/600V) and AC or DC amperage (200mA/1A/5A/shunt 50mV/shunt 100mv). Existing display options include analog process signals, load cell, or potentiometer inputs, and temperature inputs in either °F or °C from RTDs or thermocouples. All panels offer selectable decimal point location.

The ProSense DPM2 process meter series is now available with 4-digit (-1999 to 9999) 20mm character height red LED process indicator displays in addition to the existing 4-digit (-9999 to 9999) 14mm red LED displays. The ProSense DPM3 series offers 5-digit tri-color red / green / amber LED process indicator displays.

ProSense digital panel meters from AutomationDirect start at $70.00 and have a 3-year warranty.

Important Links Bar.jpg

www.automationdirect.com/digital-panel-meters.
