nVent: WeatherPro Pad-Mount Single-Door Type 3R


June 21, 2022

Introducing nVent’s WeatherPro Outdoor Pad Mount Enclosures which protect controls, drives, power distribution components or contactors in outdoor commercial or industrial power distribution and control applications. The overlapping two-door models with no center post allow full-width access to enclosure interior.












Features & Benefits

  •    –   3-point latching system with heavy duty handle
  •    –   Padlock provision in handle
  •    –   Open bottom with pre-punched mounting hole flange
  •    –   Drip edge overhang on top
  •    –   Louvered overhang with a closure plate
  •    –   Studs included for mounting optional panels on threaded bolts
  •    –   Welded body construction
  •    –   Sturdy 7 gauge lifting tabs
  •    –   Overlapping doors with no center post on two-door models
  •    –   Bonding provision on each door
  •    –   Bolted hinges on doors
  •    –   Enclosures are finished with paint over plated surfaces


https://hoffman.nvent.com/en-us/products/weatherpro-pad-mount-single-door-type-3r
