ROLEC’s IP 67 Enclosures For Tough IIoT And Smart Factory Technology


October 19, 2021

ROLEC’s newly extended aluCASE and technoPLUS electronic enclosures are popular in the fields of IIoT technology and Smart Factory automation.

These advanced enclosures are ideal for a wide range of IIoT and other industrial electronics applications in challenging indoor and outdoor environments. Both are rated IP 66 and IP 67 as standard (IP 69K optional).

Robust aluCASE and technoPLUS can both be installed ‘lid closed’ to protect the seal and electronics. Both feature a large recessed lid for fitting a membrane keypad, front plate or product label. Smart trims hide and protect the mounting and lid screws. Standard features also include lid retaining straps/hinges. Inside, there are screw bosses for installing PCBs, mounting plates and DIN rails.

Diecast aluminum aluCASE is a ‘go anywhere’ enclosure that can be mounted on machines, walls and bulkheads. It is available in 29 sizes from 2.95” x 1.96” x 1.30” to 16.93” x 11.81” x 4.72”. Two sizes can be specified with a transparent lid. The standard enclosure color is window grey (RAL 7040). Red, blue, anthracite or window gray snap-on trims have recently been added for product color coding.

Versatile technoPLUS features a unique pole-mounting attachment (accessory) that enables the enclosures to be mounted either vertically or horizontally. The housings are molded from tough and UV-resistant ASA Luran in light gray (RAL 7035) as standard. Five sizes range from 5.11” x 3.54” x 2.75” to 10.62” x 6.69” x 3.54”.

Options for aluCASE include anodized aluminum trims, integrated exterior lid hinges with no visible fixings, and key lock access for added security. Accessories for technoPLUS include mounting plates, rails and the pole-mounting attachment.

Both models can be supplied fully customized. Services include custom colors, CNC machining, engraving/laser processing, photo quality printing of legends, logos and graphics, RFI/EMI shielding, display windows and assembly.


https://www.rolec-usa.com/en/news/prg2110-alucase-technoplus-iiot-enclosures/



Post Views: 475
