Dewatering, Ventilation and Power Take-Off Panels

Eaton Power TakeOff Panels Thumbnail

September 23, 2021

Eaton’s specialized panels were specially designed for the tough pumping installations associated with applications in mining operations and tunnelling projects. The panels are intended for use in non-hazardous, resistance or solidly grounded installations and up to 600 Vac.

Core Features

  • Horsepower rated
  • Type 12 or 4 X enclosures
  • Door-mounted viewing window included as standard
  • Lifting handles installed as standard on both sides of the enclosure
  • VISA – HMCP for improved safety
  • Combination starter with visible break disconnect NEMA/IEC/vacuum contactor with C440 electronic overload relay (C441/C445 available as options) or soft starter
  • START/STOP push-buttons and MANUAL/OFF/ AUTO selector switch included as standard
  • LED lamps used on pilot lights for infinite life included as standard
  • Startco® ground-fault ground-check monitor included as standard
  • Door-mounted ground-fault and ground-check indicating lights and ground-fault/ground-check reset push-button included as standard
  • 120 Vac control power
  • cCSAus certified* with a large variety of customer specific design options
