IMO: Miniature Circuit Breakers B4/BR6/B10


May 20, 2021

The IMO range of miniature circuit breakers have been designed for protection of electrical installations against overload and short circuits and are manufactured in accordance with IEC 60898-1.

Technical Data

  •    • Handle central-tripping function for circuit fault indicating
  •    • New front design; cover and handle in arc shape
  •    • Contact position indicating window; transparent cover to carry label
  •    • High short circuit capacity
  •    • Suitable for terminal and Pin/Fork type busbar connection
  •    • Finger protected connection terminals
  •    • Handle padlock device

Tripping characteristics in accordance with B, C and D type curves

  •    • Curve B: 3-5 In
  •    • Curve C: 5-10 In
  •    • Curve D: 10-20 In

Certification: B4: Semko / CE B10: VDE / Semko / CE

For more technical information and/or similar products from IMO, visit the link below.


https://technical.imopc.com/mcbrangedatasheet071220.pdf

Check Availability
