IMO: UL 1077 Miniature Circuit Breakers


April 6, 2021

The IMO range of UL 1077 Approved Miniature Circuit Breakers have been designed for protection of electrical installations against overload and short circuits and are manufactured in accordance with UL 1077.

UL 1077 MCB Features

  • • UL1077, IEC 60947-2 & IEC 60898-1 Compliant
  • • DIN Rail Mountable
  • • 10kA Short Circuit Capacity
  • • Available from 0.5Amps to 63Amps
  • • Suitable for Supplementary Circuit Device Protection
  • • Thermo-Magnetic Overcurrent Protection
  • • B, C & D Type Tripping Curve
  • • Contact Position Indicator
  • • RoHS Compliant

Tripping characteristics in accordance with B, C and D type curves

  • • Curve B: 3-5In
  • • Curve C: 5-10 In
  • • Curve D: 10-20 In


https://technical.imopc.com/ul1077mcbdatasheet110321.pdf
