Weco Connectors: 110-M-216-SMD

February 10, 2021

The 110-M-216-SMD is a pin strip for the reflow soldering process in a horizontal version with a pitch of 3.5 mm and available in 2 to 12 poles. This product is characterized by the “Floating Anchors”. They are movable in vertical direction and achieve 100% coplanarity. Side flanges improve the stability and increase the adhesion force on the PC board. The pin strip is compatible with all standard connectors series 110 and 110-A-IDC (Insulation Displacement Contacts). The housing of the pin strips meets the requirements of the elevated soldering temperatures in the lead-free soldering process.

OPTIONS / ACCESSORIES

  •    –   CN: Consecutive Numbering
  •    –   SM: Special Marking (please provide sketch)
  •    –   G05: Gold Plating (5 micro inches)
  •    –   G30: Gold Plating (30 micro inches)
  •    –   S30: Silver Plating (30 micro inches)
  •    –   TR: Tape and Reel Assembly
  •    –   Self-Adhesive marking strip BST-3.50 [1]
  •    –   Coding keys 120-K-HT


https://www.wecoconnectors.com/en/products/110-m-216-smd/
