DATA MODUL Offers LCD Video Controller Board Family

 October 27, 2020

With its eMotion product line DATA MODUL offers LCD controller boards that are specially tailored for high performance requirements of industrial customers. All eMotion Series LCD controller boards are developed based on specific industrial requirements, such as long-term availability, quality and stability. They are available as a fully-equipped, complete LCD controller board kit (cable, converter, power supply and OSD board).

Thanks to its wide selection, the eMotion family offers boards for a variety of applications. The range of products stretches from boards for standard TFTs with single/dual-channel LVDS interface and up to 1920×1200 pixels to boards for TFTs with quad-channel LVDS, eDP ( up to 8 lanes ), VbyOne ( 8 lanes ) with a resolution of up to 3840 x 2160. Multiple video inputs can be supported, like DisplayPort, VGA(RGB), DVI, HDMI, CVBS/YC. Other special features which can be integrated are DDC/CI support, OSD through RS232, PIP, PBP or FRC, ambient light sensors and proximity sensors, daisy chain function for video wall applications allowing monitor makers to create sophisticated products.

Data Modul programs and optimizes its eMotion boards to match specific sizes and resolutions of LCD displays. The series supports all key LCD lines from DATA MODULs partners such as AUO, Innolux or KOE and every board solution comes configured as complete LCD controller board kit including LCD cable, LED driver and cable as well as along with an OSD Board. Therefore, and due to its wide range of sizes and functions, Data Modul offers the right solution for every display controller need.

All boards are developed by Data Modul’s in-house R&D department and manufactured in Germany, offering highest quality, product stability and long-term availability.



More information on the eMotion Series

Contact DATA MODUL Sales Team
