Advanced Energy Xsolo
Advanced Energy Xsolo Ultra-Compact Single Output Power Supplies



Mouser Electronics has announced an extended global distribution agreement with Advanced Energy to distribute Excelsys Technologies products. Through the agreement, Mouser Electronics is now stocking Excelsys low-voltage power supplies.

The Xsolo series ultra-compact, single-output power supplies provide 500 W in a convection-cooled chassis or up to 1008 W in an enclosed, fan-cooled chassis. Offering an output current range of 10.5 A to 42 A and an input voltage range of 85 VAC to 264 VAC at greater than 92 percent efficiency, the power supplies are ideal for industrial, communication, and test and measurement applications.

The UltiMod series devices are modular switch-mode power supplies that consist of AC input front ends (powerPacs) and single- and dual-output modules (powerMods). The powerPacs are available in two versions: the UX4, which delivers up to 600 W and can be populated with up to four powerMods, and the UX6, which delivers up to 1200 W and can be populated with up to six powerMods. Typical applications for the UltiMod series include medical equipment, industrial automation and machines, test and measurement, printing, telecommunications, audio, and broadcast equipment.

Mouser also now stocks the CoolX®600 and CoolX1800 modular power supplies. Offering best-in-class conversion and exceptional reliability, the convection-cooled CoolX600 series delivers 600 W of output power at efficiencies up to 94 percent. The devices are designed to meet both medical and industrial global safety specifications at 5000 meters altitude, including in harsh, remote applications subject to input voltage line surge disturbances of up to 300 VAC.

The CoolX1800 series is an intelligent modular power supply platform that delivers 1800 W of output power via PMBus™ digital communications and control. The CoolX1800 offers system designers in the medical and industrial electronics industries increased efficiency and reliability, in addition to a comprehensive feature set and specifications.

XF series low-voltage power supplies provide up to 1000 W in an extremely compact 268 mm × 127 mm × 1U design. The XF family features plug-and-play architecture for maximum flexibility, allowing custompower-solution configuration in less than five minutes. Offering up to 12 isolated outputs, the XF platform can provide output voltages up to 348 VDC in harsh industrial, test and measurement, communications, fixed and mobile radar, and military electronics applications that require off-the-shelf solutions.



Xsolo series datasheet

UltiMod series datasheet

CoolX 600 datasheet and CoolX 1800 datasheet

XF Series datasheet
