WAGO Touch Panel 600 CP and I/O Saves Costs
December 30, 2019
WAGO’s new line of Operator Interface devices, the Touch Panel 600 line, brings high-tech screens and high quality visualizations to allow users to accompany their machines with advanced features. When used with theWAGO-I/O-SYSTEM, the WAGO TP 600 Control Panel (PLC + HMI) combines the features of a PLC and a HMI into a single device providing a compact footprint for an automaton system. The WAGO-I/O-SYSTEM expands the TP 600’s I/O capabilities with seamless integration of over 500 (digital, analog and special function) I/O modules. The control panel saves costs by eliminating extra hardware (for example, a separate PLC) and further reduce space and programming time.
The engine has a Cortex A9 multicore processor providing fast operating speeds. On board security include a built in firewall and VPN to help users address cyber attaches. All panels are equipped with the future-ready Linux operating system and support HTML5 technology.
The Touch Panel 600 line includes three versions to give users flexibility to use the right technology that fits their application and budget. These versions include:
- Control Panel: Offers control and visualization to be performed simultaneously for an all in one automation solution
- Visu Panel: Offers greater performance by splitting the responsibility of control and graphic visualization with the PLC controller
- Web Panel: An industrial web browser optimized to operate with WAGO’s e!COCKPIT based PFC100 and PFC200 controllers
All of the Touch Panel 600s offer practical features such as an energy-saving standby function, integrated sensors for automatic brightness adjustment and an easy-to-mount design to make installation and operation simple.
- Quad core processor for high performance control as well as high resolution graphics
- Linux® operating system allows you to run applications in parallel with PLC code
- Support of MQTT and OPC UA protocols to easily connect your plant floor data to your preferred Cloud service
- Multiple fieldbus ports on board support Modbus TCP, CANopen, and EtherNet/IP (adapter mode) protocols
- Onboard configurable serial port (RS-232/485) can be used to connect to additional field devices
For optimal automation both inside and outside the control cabinet: the flexible IP20 and IP67 remote I/O systems for all applications and environments.
- Fieldbus-independent: Compatible with all standard fieldbus protocols and ETHERNET standards
- Wide variety of I/O modules available for nearly every application
- International and national approvals for worldwide use
- Extensive range of accessories for marking and connection technology
- IP20 I/O systems – equipped with CAGE CLAMP® technology for rapid, vibration-proof, maintenance-free connections
More information on WAGO Touch Panels 600
