Load Feeder Dimensioning and Cable Sizing Made Easy

June 16, 2020

The correct electrical load feeder dimensioning is often a challenge for both machine and panel builder. With the load feeder configurator+ (IEC) Siemens will show you how to overcome this.

In this webinar, Siemens would like to provide you a standard conform summary on:
   • how to do the correct electrical dimensioning of motor starters in terms of load feeder protection devices and
   • the correct dimensioning of power conductors.

The new load feeder configurator+ (IEC) ensures an efficient and time saving dimensioning of load feeders and therefore avoids harmful influences on your electrical control panel.

Join us for a short introduction of this engineering tool and ask the experts directly if you have any questions.

Important Links Bar.jpg

Register for the webinar on June 30th and take part in the first session at 9 AM (UTC+01) or second session at 4 PM (UTC +01).

Post Views: 370
