Heat in the Control Panel? Verification Made Easy

July 14, 2020

Are you aware of the influence of ambient conditions such as heat, cold, and condensation that cause temperature rise in your industrial control panel?

The appropriate designing of electrical control panels in terms of abnormal temperature is one of the biggest challenges towards the standard compliant electrical machinery equipment.

What does the temperature rise evaluation involve?
   • technical standards and product related requirements and
   • technical risk assessment with reliable temperature rise evaluation methods for the documentation of an industrial control panel.

Siemens provide you tips and tricks for selecting the reliable equipment, as well as standard compliant dimensioning and temperature assessment for industrial control panels with SIMARIS therm.

Join in for a short introduction to the engineering tool and ask the experts directly if you have any questions.

Register for the webinar on July 29th and take part in the first session at 9 AM (UTC+01) or second session at 4 PM (UTC +01).

Important Links Bar.jpg

Register HERE for 9 AM Session

Register HERE for 4 PM Session
