ERNI continues to expand its interconnect solutions designed for programmable logic/automation controllers, distributed control systems, remote I/O and other industrial automation applicaitons.Connectors offering 1.27 mm [.050”] pitch or less are becoming more common, while open pinfield interfaces offer the user maximum design flexibility for low speed and higher speed differential data.
Designed to replace traditional terminal blocks, the EF2 Series Zero ScrewTM connector delivers quick and secure one-step connection. By eliminating the need for screws, the EF2 Series terminals do not require inspection or retightening to ensure a stable and consistent connection like traditional terminal blocks. As a result, the screwless terminal block series significantly reduces the electrical wiring time and maintenance workload compared to conventional terminal blocks.
The AB-CO PURGE Model AP-01Z-02 Purge and Pressurization System is a Z-Type system designed specifically for small electrical enclosures with volumes up to 2 cubic feet (0.056 cubic meters). As a Z-Type purge and pressurization system, the Model AP-01Z-02 reduces the classification within the electrical enclosure used in a Class I, Division 2 (Groups A,B,C,D) and Class II, Division 2 (Groups F&G) hazardous environment from Division 2 to unclassified.
Sealed from both above and below the mounting surface, the rugedized RAMO Series emergency stop switches from RAFI offer an innovative solution that allows customers to reduce assembly time and wiring errors.
Orion Fans has expanded its DC axial fan product family with the addition of nine new IP68-rated series. Offering protection from dust and water, the IP68-rated DC fans are designed for a wide range of harsh environment applications.
Laird Thermal Systems’ highly efficient thermoelectric assemblies (TEAs) significantly improve performance and lowers operating costs of applications in rugged outdoor environments. Designed for applications like outdoor kiosks, battery backup cabinets, enclosures, and electronic cabinets, the Outdoor Coolers run at nominal voltages at either 24 or 48 VDC and offer dependable cooling capacities ranging from 100 to 480 Watts.
B&R Automation’ PS3050 3 Phase Power supply provides 24VDC, 5A. The connection terminals and control elements are clearly arranged on the front side and are clearly labeled. The terminals are easily accessible on the bottom and/or top edges on the front of the unit. The large size and stability of the terminals also allow the use of a battery-operated screw driver.
CENTUM VP R6.07 has been enhanced to enable communication with devices that support the PROFINET Industrial Ethernet standard. Also, new functions have been added to the Automation Design Suite (AD Suite) integrated engineering environment to improve engineering efficiency. These enhancements address the latest customer needs and boost productivity.
The YS1700 Programmable Indicating Controller can be tailored for various applications by running a user program, and offers high reliability thanks to Yokogawa’s proprietary technology, user friendliness, and expandability. Standard models are smaller and lighter than earlier series, requiring less space for installation, and are compliant with international safety standards including the CE Mark and FM nonincendive (optional) approvals.
Revolutionary energy efficiency through innovative hybrid technology. On average, 75% energy saved due to speed-regulated components and heat pipe technology. Suitable for international use due to a unique multi-voltage capability. Intuitive operation via touch display. Identical mounting cut-out (external mounting, partial internal mounting and full internal mounting) for four output categories.
These single door wallmount enclosures can be used for virtually any application. The WM series ensures NEMA protection through a secure locking system, foamed-in-place gasket, and knife-edge sealing surface. Features include a cold rolled steel body and door, and a zinc plated mounting panel.
Hammond Manufacturing’s Type 12 Mild Steel Two Door Freestanding Enclosure is designed to house electrical, electronic, hydraulic or pneumatic controls with provision for panel mounting or rack mounting of equipment. It provides a degree of protection from falling dirst, dust, oil and water and is available with front access only or both front and rear access. It also has a variety of inner panels, rack mounting angles and swing frames are are also available.
The PowerXL DA1 advanced variable frequency drive is ideal for demanding applications that are speed- and torque-dependent. Eaton’s PowerXL product family delivers outstanding performance regarding motor control and modularity.
Multi-touch panels open up new dimensions for innovative HMI design. There are numerous gestures that might be used in an application: zooming in and out and rotating objects with two fingers, scrolling through lists and switching to the next screen with a quick swipe. The main advantage of multi-touch technology is how it makes operation more intuitive.
The XP500 series from Eaton sets a new standard for advanced intuitive HMI and SCADA technology. Capacitive multi-touch displays allow the use of multiple fingers to zoom, scroll and swipe. It’s about time that the gesture controls that have benefited smartphones and tablets came to the industrial world.
Manufacturers change their products – and you: You change your project. It can be laborious when working on a control cabinet, but Pro Panel Version 2.8 simplifies the process. In the layout navigator, you can exchange parts without deleting the existing part placement from the original control cabinet.
And it’s not a problem if the new cabinet part has several macro variants: You simply select one of the variants before the exchange (e.g., control cabinet with door hinges on the right or left). After part selection, the “select macro variant” dialogue opens automatically.
Different types of constructions for a control cabinet can be saved as variants of a 3D macro in the master data and, if needed, exchanged in a positioned control cabinet via a part swap. It’s very easy!
